無線充電器FCC認證標準介紹

2019-12-01
9427 作者: 北測集團

Wireless power transfer (WPT) devices operating at frequencies above 9 kHz are intentional radiators and are subject to either Part 15 and/or Part 18 of the FCC rules. The specific applicable rule part depends on how the device operates, and if there is communication between the charger and device being charged.

Intentional radiators transmitting information must be certified under the appropriate Part 15 Rules and will generally require an equipment certification. A WPT device may operate in two different modes: charging and communications. It is possible for the device to be approved under Part 18 for the charging mode and Part 15 for the communications mode, if it can be shown that (1) the device complies with the relevant rule parts; and (2) the functions are independent. Part 18 consumer devices can be authorized using either certification or SDoC, once the appropriate RF exposure evaluation has been completed.



針對于工作頻率高于9 kHz的無線能量傳輸設備,無線充電器的標準可以是FCC認證標準中的part 15部分 或 part 18部分,需要受到FCC認證標準中第15部分和/或第18部分的約束。 具體適用的規則部分取決于設備如何操作,以及充電設備和接受充電的設備之間是否有通訊。


傳輸信息的散熱器必須根據相應的第15部分規則進行認證,并且通常需要設備認證。在FCC第15標準中,無線充電器做FCC認證,在FCC-SDOC中標準是PART15 B,在FCC-ID中標準是PART15C。


WPT設備可以以兩種不同的模式操作:充電和通信。 如果可以證明(1)設備符合相關規則部分,則可以根據第18部分批準設備用于充電模式,第15部分用于通信模式; (2)職能是獨立的。 一旦完成適當的RF暴露評估,第18部分消費者設備可以使用認證或SDoC進行授權。無線充電器做FCC認證充電模式可以做part 18標準, 通訊模式可以做part 15標準. 這兩個標準都需要增加RF exposure evaluation。
